LANCER Cluster Conversion (miles/km) + Cluster Dumps

Description

This covers Cluster conversion for Mitsubishi Lancer Evolution 10 (EVO X) but checking base Lancer EEPROM dumps I would say it should work for other Lancer models. By the way – you can swap these EVO clusters to base models too! Facelift ones (from year 2011) are multi-color, EVO clusters have dials pointing downwards and overall look is way better than base Lancer.

The cost for parts required to make this are about 100€. Electronics can be acquired in any electronic parts store (like RadioShack, Digi-Key or similar) for below 10€ and replacement faces did cost me ~60€ (found here). You can purchase EEPROM reader, if making it yourself is not an option, and there are variety of them, so it depends on your preference (so price of it is not included).

Europe EVO X clusters goes for A LOT of money, they are very rare and mostly unattainable. USA clusters can be purchased for about 250€. You can have a perfectly working EU cluster in KMH for as low as 330€ if you do this conversion.

• Cluster Dumps Only (GN-CLDUMPS)–In the file you will find these ROM / EEPROM .bin files:

  Mitsubishi Lancer EVO X – 93C76 – 46123m – 8100C065
  Mitsubishi Lancer EVO X – 2008 – 93C86 – 42345km – 8100A317
  Mitsubishi Lancer EVO X – 2008 – 93C86 – 89878km – 8100A317
  Mitsubishi Lancer EVO X – 2011 – 93C86 – 81004m – 8100B460
  Mitsubishi Lancer EVO X – 2013 – 93C76 – 4500m – 8100C065
  Mitsubishi Lancer EVO X – 2013 – 93C76 – 5647m – 8100C065
  Mitsubishi Lancer EVO X – 2013 – 93C86 – 22000m – 8100B460
  Mitsubishi Lancer X – 93C76 – 37669km – 8100C351
  Mitsubishi Lancer X – 93C86 – 138000km – 8100B127
  Mitsubishi Lancer X – 93C86 – 181577km – 8100B366
  Mitsubishi Lancer X – 2010 – 93C76 – 58200km – 8100C331
  Mitsubishi Lancer X – 2010 – 93C86 – 9300km – 8100A117
  Mitsubishi Lancer X – 2010 – 93C86 – 60000km – 8100B361
  Mitsubishi Lancer X – 2010 – 93C86 – 94338km – 8100B261
  Mitsubishi Lancer X – 2010 – 93C86 – 155934km – 8100B196
  Mitsubishi Lancer X – 2010 – 93C86 – 297514km – 8100B127
  Mitsubishi Lancer X – 2011 – 93C86 – 30230km – 8100B361
  Mitsubishi Lancer X – 2011 – 93C86 – 220271km – 8100B361
  Mitsubishi Lancer X – 2011 – 93C86 – 354888km – 8100B366
  Mitsubishi Lancer X – 2013 – 93C76 – 17000km – 8100B821
  Mitsubishi Lancer X – 2014 – 93C76 – 82991km – 8100C031
  Mitsubishi Lancer X – 2014 – 93C76 – 90016km – 8100C031
  Mitsubishi Lancer X – 2014 – 93C76 – km – 8100B821
  Mitsubishi Lancer X – 2015 – 93C76 – 70000km
  Mitsubishi Lancer X – 2015 – 93C76 – 85000km – 8100C331
  Mitsubishi Lancer X – 2015 – 93C76 – 228677km – 8100C331
  Mitsubishi Lancer X – 2015 – 93C76 – 254841km – 8100C331


• Cluster Conversion Document and Cluster Dumps (GN-CLUSTER) includes:

  PDF Document explaining how to read/change/write EEPROM to convert the cluster units
  Archive with all the Cluster Dumps listed above

Cluster removal: https://www.youtube.com/watch?v=LKV3womYczw
Change cluster faces: https://www.youtube.com/watch?v=GsMDy0UwSDw
A good and cheap EEPROM programmer – minipro (tl866) https://www.aliexpress.com/item/1005005302276053.html

After successful payment an automated e-mail will be sent to your address with the download link and instructions for the file. Thanks for your support!

Take a look at this video for more information:
